Steel framing demands accuracy from the very first line. Misaligned tracks, misplaced openings, or coordination errors quickly cascade into delays across drywall, MEP, and finishes.
With LightYX, coordinated CAD or BIM models are projected directly onto hard floor and ceiling surfaces, giving crews clear, visual guidance they can build from immediately. No tape measures. No chalk lines. No guessing. Whether you’re laying out light-gauge walls, interior steel partitions, or architectural framing, LightYX turns digital design into full-scale, on-site layout — helping teams move faster while building exactly to plan.
What LightYX Does for Steel Framing
LightYX enables confident layout from day one by projecting:
- Light-gauge steel track lines
- Interior and exterior steel partitions
- Door and opening rough-ins
- Wall offsets and radius conditions
- Backing and support locations
- Wall type labels and layout annotations
- Ceiling references for vertical alignment
All projected directly where crews work — on floors and ceilings — so installation starts immediately with clarity.
Why Steel Framers Choose LightYX
- Start Building Sooner – Instant laser layout replaces measuring and chalk lines.
- Improve Accuracy Across Trades – Keeps steel aligned with drywall, MEP, and architectural details.
- Handle Complex Geometry with Ease – Simplifies offsets, radius walls, and mixed wall types.
- Project on Floors and Ceilings – Enables precise soffits, bulkheads, and vertical alignment.
- Scale Easily on Repetitive Projects – Delivers consistent, model-based layout on every level.
How It Works
- Import your coordinated CAD or BIM files
- Align LightYX to your jobsite control
- Project full-scale steel layout on floors and ceilings
- Crews frame directly to what they see
- Reduce layout time, coordination errors, and rework
Simple, visual, and built for real jobsite conditions.
Built for Commercial Steel Framing
LightYX supports steel framing workflows across office and tenant improvement projects, multifamily and mixed-use buildings, healthcare and education facilities, and hospitality and retail interiors.
Anywhere light-gauge steel meets tight schedules and complex coordination, LightYX helps teams deliver faster with higher confidence.
Get started with LightYX Steel Framing Layout — turn coordinated drawings into clear, actionable steel layout on floors and ceilings so your crews build right the first time.
Steel contructor ? Speed Up Layout
CONTACT US
%201.png)
FAQ
How does LightYX improve light-gauge steel framing layout?
LightYX projects steel track lines, partition locations, rough openings, radius conditions, offsets, backing locations, and wall labels directly onto floors and ceilings. Steel framing crews can work from a visible full-scale layout instead of relying on manual measurements and chalk lines.
Why is steel framing layout difficult on complex commercial projects?
Steel framing errors often cascade into drywall, MEP, doors, ceilings, and finishes. Complex geometry, mixed wall types, openings, shafts, and coordination with other trades make manual layout slow and vulnerable to mistakes.
How does LightYX reduce rework in steel framing?
LightYX reduces rework by helping crews build from coordinated CAD or BIM files projected directly on the jobsite. This reduces misaligned tracks, wrong openings, incorrect offsets, and layout inconsistencies between floors and ceilings.
How can steel framing crews improve top-track and bottom-track alignment?
LightYX supports projection on both floor and ceiling surfaces, helping crews align bottom track and top track more accurately. This is useful for interior partitions, soffits, bulkheads, and vertical alignment across the framing scope.
How does digital laser layout help steel framing contractors scale across repetitive floors?
On repetitive commercial or multifamily projects, LightYX helps crews repeat the same coordinated layout consistently across levels. This reduces setup time, improves quality control, and helps standardize production from floor to floor.
